SPESIFIKASI
Model : PBZ 650W 80+ Bronze
Form Factor : ATX
Dimensions : 140(L) x 150(W) x 85(H)mm
Voltage Range : 90 – 260V
Current : 6A
Frequency : 47 – 63Hz
80 PLUS Certification Bronze
DC OUTPUT
Red +5V (10A)
Orange +3.3V (10A)
Yellow +12V (54A)
Blue -12V (0.3A)
Purple +5Vsb (2.0A)
POWER CONNECTOR
Main Power (24 pin) 1
ATX 12V (4+4 pin) 1
PCI-E (6+2 pin) 2
Sata (4 pin) 4
Safety Features OVP (Over Voltage Protection)
SCP (Short Circuit Protection)
UVP (Under Voltage Protection)
OPP (Over Power Protection)
