UPS APC BVX1200Li-MS
UPS Features & Benefits :
– Advanced Safety Features
– Intelligent battery management
– Battery failure notification
– Safety-agency approved
– Battery and surge protected outlets
– LED Indicators
– Sleek design
– Transformer-block spaced outlets
– Boost Automatic Voltage Regulation (AVR)
– Cold-start capable
Technical Specifications :
– Max Configurable Power (Watts) : 650 Watts / 1.2kVA
– Output Frequency (sync to mains) : 50/60 Hz +/- 1 Hz Sync to mains
– Topology : Line interactive
– Waveform type : Stepped approximation to a sinewave
– Transfer Time : 6 ms typical : 10 ms maximum
– Input frequency : 50/60 Hz +/- 5 Hz Auto-sensing
– Input voltage range for main operations : 140 – 300 (230 V) VAC
– Input Power Factor at Full Load : 0.51
– Battery type : Lead-acid battery
– Typical recharge time : 8hour(s)
– Nominal Battery Voltage : 12V
– Expected Battery Life (years) : 1 – 2
– Battery Volt-Amp-Hour Capacity : 108
– Control panel : LED Status display with on line : on battery
– Audible Alarm : Alarm when on battery : distinctive low battery alarm
– Surge energy rating : 273Joules
– Physical Maximum (Height x Width x Depth) : 190MM x 140MM x 390MM
– Physical Shipping (Height x Width x Depth) : 297MM x 235MM x 495MM
– Physical Net Weight : 7.5KG
– Physical Shipping Weight : 8.5KG
– Protection Class : IP20
– Operating Temperature : 0 – 40 °C
